A PTFE lined plug valve is a valve in which a PTFE lined metal body is utilized for corrosion protection as well as for tight sealing. It consists of a tapered plug that turns inside the PTFE sleeve to regulate fluid flow. PTFE lined plug valves can be utilized to handle aggressive, corrosive, and high-temperature fluids and are excellent in chemical resistance, low in friction, and highly durable in the long term and can be utilized in numerous industrial processes.
Size : 25 NB TO 80 NB.
Flange Connection : ANSI B 16.5
Face to Face : ANSI B 16.10
Spark Test : 15 KVA
Hydro Body Test : 15 kg/cm2.
Hydro Seat Test : 10 Kg/cm2.
Leak Test : as per API 598.
Temperature : FEP –Max 180 Degree Celsius PFA Max: 200 Degree Celsius.
Grayson PTFE Lined Pipe is a leading supplier of PTFE Lined Plug Valve in Midland, UK, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
|
SIZE |
L |
G |
H |
|
15 |
108 |
158 |
95 |
|
20 |
117 |
228 |
100 |
|
25 |
127 |
228 |
105 |
|
40 |
165 |
325 |
130 |
|
50 |
178 |
325 |
140 |
|
80 |
203 |
548 |
170 |
|
100 |
228 |
548 |
217 |
|
150 |
268 |
575 |
300 |
The PTFE lining protects against harsh chemicals, making the valve ideal for corrosive applications.
PTFE-lined plug valves offer a tight, leak-free seal, making them ideal for applications where leak prevention is crucial.
These valves can withstand high temperatures without degrading, ensuring reliable performance in thermal processes.
Thanks to their durability, PTFE-lined plug valves minimize downtime and reduce maintenance costs, making them a cost-effective choice for industrial applications.
These valves function by rotating a tapered plug within the valve body to regulate or block fluid flow. The PTFE lining ensures smooth, low-friction operation while providing excellent wear and chemical resistance.
PTFE Lined Plug Valves are available in a range of sizes from 1/2 inch to several inches, accommodating various flow rates and industrial applications.
Regular inspections and cleaning are essential to ensure optimal performance. PTFE lining should be checked for wear, and moving parts should be lubricated to prevent sticking or seizing.
PTFE lined plug valves are typically made with a carbon steel or stainless steel body, internally lined with PTFE. This design enhances corrosion resistance, strength, and durability, even in aggressive chemical environments.
PTFE lined plug valves are typically made with a carbon steel or stainless steel body, internally lined with PTFE. This design enhances corrosion resistance, strength, and durability, even in aggressive chemical environments.
